VDE8043 series 0.5 square double-insulated PTFE high-temperature wire

The VDE8043 Series 0.5mm² Double Insulated Teflon High-Temperature Wire represents premium-grade electrical wiring solution designed for extreme environment applications. This wire features a unique double-layer Teflon insulation construction with a conductor cross-section of 0.5mm², providing enhanced safety and reliability. Certified to VDE8043 standards, it offers exceptional thermal stability and electrical performance in demanding conditions where conventional wires would fail.

Inquiry

E-mail：2314093856@qq.com

Detailed Description

Product parameters

Rated voltage: 300/500V

Temperature range: -40℃ to +180℃

Conductor: Tin-plated copper wire

Insulator: FEP

Outer cover: FEP

Safety standard: DIN VDE0207

Color: White - blue - red - Black - brown - yellow - green - transparent

Product features: Thermosetting product, heat-resistant, acid-resistant, alkali-resistant, oil-resistant, flame-retardant.

Scope of application: It is applicable to connection lines of household appliances, lighting fixtures, electronic tools, temperature sensors, aerospace, military products, communications, automobiles, ships, power installation, etc.

Product Description

The VDE8043 Series 0.5mm² Double Insulated Teflon high-temperature wire represents premium-grade electrical wiring solution designed for extreme environment applications. This wire features a unique double-layer Teflon insulation construction with a conductor cross-section of 0.5mm², providing enhanced safety and reliability. Certified to VDE8043 standards, it offers exceptional thermal stability and electrical performance in demanding conditions where conventional wires would fail.

Engineered with precision German standards, this wire combines advanced fluoropolymer insulation technology with robust copper conductors to deliver unmatched performance in high-temperature applications. The double insulation design provides an extra layer of protection against electrical leakage and physical damage, ensuring maximum safety in critical applications.

Product Features

Dual-Layer Insulation Design

Two independent Teflon insulation layers
Enhanced electrical insulation performance
Improved mechanical protection
Redundant safety barrier

Exceptional Thermal Characteristics

Continuous operation: -60°C to +250°C
Short-term withstand: Up to 300°C
Excellent thermal shock resistance
Minimal thermal deformation

Superior Electrical Properties

Dielectric strength: ≥8000 V/mm
Insulation resistance: ≥10¹⁸ Ω·cm
Low dielectric constant: 2.0-2.1
Excellent high-frequency performance

Chemical and Environmental Resistance

Resistant to acids, alkalis, and solvents
UV radiation resistant
Moisture proof (0% absorption)
Ozone resistant

Mechanical Durability

Excellent abrasion resistance
Good cut-through protection
Maintains flexibility after thermal cycling
High tensile strength

Product Advantages

Enhanced Safety
Double insulation design provides redundant protection against electrical shock and short circuits, significantly improving application safety in critical environments.

Extended Service Life
Superior thermal and chemical resistance properties ensure longer service life in harsh conditions, reducing replacement frequency and maintenance costs.

Space Efficiency
Compact design with 0.5mm² cross-section saves space in high-density wiring applications while maintaining excellent current carrying capacity.

Installation Flexibility
Maintains flexibility across the entire temperature range, allowing easy installation in complex routing scenarios and tight spaces.

Reliability Assurance
VDE8043 certification guarantees consistent quality and performance, ensuring reliability in mission-critical applications where failure is not an option.

Application Areas

Industrial Heating Systems

Industrial oven wiring
Heating element connections
Thermal processing equipment
Furnace instrumentation

Power Electronics

Transformer connections
Power supply wiring
Inverter systems
Energy storage systems

Automotive Electronics

Engine compartment wiring
Exhaust system sensors
Transmission control systems
Electric vehicle power systems

Aerospace and Defense

Aircraft engine monitoring
Avionics systems
Military vehicle electronics
Satellite systems

Medical Equipment

Diagnostic imaging systems
Sterilization equipment
Laboratory analyzers
Surgical instruments

Renewable Energy

Solar power systems
Wind turbine generators
Battery storage systems
Power conversion equipment

Frequently Asked Questions (FAQ)

Q: What is the advantage of double insulation design?
A: Double insulation provides enhanced electrical safety, better mechanical protection, and improved reliability in high-vibration environments.

Q: Can this wire be used in outdoor applications?
A: Yes, the UV-resistant Teflon insulation makes it suitable for outdoor use in various weather conditions.

Q: What is the current rating for 0.5mm² wire?
A: Typically 10-12 amps at 20°C, depending on installation conditions and environmental factors.

Q: Is the wire flexible at low temperatures?
A: Yes, it maintains flexibility down to -60°C, making it suitable for cryogenic applications.

Q: Can it withstand soldering temperatures?
A: Yes, the Teflon insulation can withstand typical soldering temperatures without degradation.

Q: Are custom lengths available?
A: Yes, we can provide custom cut lengths with stripped ends for production quantities.
