UL1332 20-30AWG insulated FEP PTFE high-temperature wire

UL1332 20-30AWG Insulated FEP Teflon High-Temperature Wire is a premium electronic wire designed and manufactured by Dongguan Zhihe Cable Technology Co., Ltd. This wire features a conductor made of silver-plated or nickel-plated copper, insulated with Fluorinated Ethylene Propylene (FEP), a high-performance Teflon material. It is specifically engineered to operate reliably in extreme temperature environments, ranging from -65°C to +200°C. The wire complies with UL1332 standards and is suitable for a wide array of high-frequency and high-temperature applications.

Inquiry

E-mail：2314093856@qq.com

Detailed Description

Product parameters

Product Model: UL1332FEP fluoroplastic wire

Temperature range: -40℃ to +200℃

Rated voltage: 300V

Wire: Tin-plated copper wire

Wire size: 20-30AWG

Insulator: FEP

Product features: Thermosetting product, heat-resistant, acid-resistant, alkali-resistant, oil-resistant, flame-retardant.

Product application: Household appliances, lighting fixtures, electronic tools, temperature sensors, aerospace

Product Description

UL1332 20-30AWG Insulated FEP Teflon high-temperature wire is a premium electronic wire designed and manufactured by Dongguan Zhihe Cable Technology Co., Ltd. This wire features a conductor made of silver-plated or nickel-plated copper, insulated with Fluorinated Ethylene Propylene (FEP), a high-performance Teflon material. It is specifically engineered to operate reliably in extreme temperature environments, ranging from -65°C to +200°C. The wire complies with UL1332 standards and is suitable for a wide array of high-frequency and high-temperature applications.

Available in a variety of AWG sizes from 20 to 30, this wire is ideal for precise electronic and electrical connections where space, weight, and performance are critical. Its construction ensures minimal signal loss, excellent electrical properties, and long-term durability even under continuous thermal and mechanical stress.

Product Features

Temperature Resistance: Capable of withstanding temperatures from -65°C to +200°C.

High Frequency Performance: Low dielectric constant and dissipation factor ensure stable signal transmission.

Chemical Resistance: Resists acids, oils, solvents, and other chemicals.

Flame Retardant: Meets UL VW-1 flame test standards.

Flexibility: Maintains flexibility across a wide temperature range.

Color Coding: Available in multiple standard colors for easy circuit identification.

Certifications: UL listed, CSA certified, and compliant with RoHS and REACH regulations.

Product Advantages

Durability: FEP insulation offers excellent cut-through and abrasion resistance.

Performance Stability: Stable electrical properties across varying temperatures and frequencies.

Easy Processing: Suitable for automated wiring and termination processes.

Lightweight and Space-Saving: Thin wall insulation helps save space and reduce weight in compact designs.

Long Service Life: Resists aging, oxidation, and environmental degradation.

Application Fields

UL1332 FEP Teflon wire is widely used in industries requiring high reliability under extreme conditions:

Aerospace: Wiring for avionics, navigation systems, and in-flight entertainment systems.

Automotive: Engine compartments, sensors, and LED lighting systems.

Medical Equipment: Internal wiring of medical devices, diagnostic imaging, and surgical tools.

Industrial Electronics: Power supplies, transformers, motors, and heating elements.

Telecommunications: RF coaxial cables, antenna systems, and data transmission equipment.

Consumer Electronics: High-end audio systems, gaming consoles, and internal computer wiring.

Frequently Asked Questions (FAQ)

Q1: What is the maximum voltage rating for UL1332 wire?

A: The voltage rating depends on the wire gauge and insulation thickness. Typically, it ranges from 300V to 600V.

Q2: Can this wire be soldered directly?

A: Yes, the tin, silver, or nickel-plated conductors allow for easy soldering.

Q3: Is the wire resistant to UV exposure?

A: Yes, FEP insulation has excellent resistance to UV and outdoor environmental conditions.

Q4: Can the wire be used in plenum spaces?

A: This wire is not specifically rated for plenum spaces. For plenum applications, please check our UL1333 series.

Q5: Are custom lengths and colors available?

A: Yes, we offer customization in length, color, and packaging based on customer requirements.

Q6: Does the wire support repetitive flexing?

A: While it is flexible, it is not designed for continuous flexing applications. For dynamic flexing, consider our Teflon PFA series.
